User Manual#

tibs is a Rust-backed Python library for creating, manipulating and interpreting binary data. It’s designed to be lightweight and easy to use, and does not assume everything fits neatly into bytes: fields can have many different interpretations and be any number of bits long.

The two most important classes in the module are:

Tibs — an immutable sequence of bits (‘tibs’ is ‘bits’ rearranged).
Mutibs — a mutable sequence of bits (‘mutibs’ is a mutable tibs).

They relate to each other just as bytes relates to bytearray: the immutable one gives stable values, hashing and cheap slices; the mutable one gives in-place edits. The constructors and most methods are shared, so throughout the manual an example using one usually applies equally to the other.

What Tibs is#

A Tibs is a sequence of bits — like bytes, but the unit is the bit and the length can be anything. That sequence is the whole object: you slice it, concatenate it, search and replace inside it at bit granularity, or pin searches to byte boundaries for stream parsing.

On top of those bits, the same object gives you two lenses — two ways of reading and writing the sequence without ever copying it into another type:

Typed fields. Read and write integers, floats and strings of any bit length, with views handling byte order and LSB0 bit labels for you.
A set of bits. Bitwise algebra, cardinalities and set predicates, with no intermediate object built along the way.

These aren’t separate modes or separate types — it’s one object, and the lenses are just different questions you ask of the same bits.

Quick taste#

Build a packet from mixed pieces, split it into fields, and read each field as a typed value:

>>> packet = Tibs.from_joined(["0b1010", Tibs.from_u(3200, 12), b"OK"])
>>> packet
Tibs('0xac804f4b')
>>> flags, size, payload = packet.split_at([4, 16])
>>> flags.bin, size.u, payload.bytes
('1010', 3200, b'OK')

The same object also answers set-style questions about its bits — here, whether every required capability bit is granted:

>>> required, granted = Tibs('0b0010_1000'), Tibs('0b1010_1100')
>>> required.is_subset_of(granted)
True

That is the sequence, the typed-fields lens and the set-of-bits lens, all on one value. The Examples work through larger versions of the same ideas.

Constructors at a glance#

Both classes offer a wide range of from_ constructors. Those that build from raw bit material are covered in The sequence of bits; those that encode typed values are covered in Typed fields.

Raw bit material	Typed values
`from_zeros()`, `from_ones()`, `from_random()`	`from_u()`, `from_i()`, `from_f()`
`from_bin()`, `from_oct()`, `from_hex()`, `from_string()`	`from_value()`, `from_values()`
`from_bytes()`, `from_bools()`, `from_joined()`

Automatic promotion#

Rather than calling a constructor explicitly, you can call Tibs (or Mutibs) directly and let it work out what you gave it. It delegates to Tibs.from_string() or Tibs.from_bytes() for strings and bytes-like types, and accepts strict list/tuple bit patterns directly:

s = Tibs('0xabc')     # Same as Tibs.from_string('0xabc')
t = Tibs([1, 0, 1])   # Strict list/tuple bit-pattern shorthand
u = Tibs(b'hello')    # Same as Tibs.from_bytes(b'hello')

This promotion is pervasive: most methods that take a bit sequence will also accept any of these types and promote it for you. So instead of

t = Tibs.from_random(1_000_000)
c = t.count(Tibs.from_bools([1, 0, 1]))

it’s more natural to write:

c = t.count([1, 0, 1])

Using promotion is generally recommended for conciseness and clarity. The one exception is performance-critical code, where avoiding the small overhead of examining and dispatching on the type can matter — there an explicit from_ method is preferred. See Building from raw bits for the exact promotion rules.

Getting started#

To install use

pip install tibs

There are pre-built wheels for most configurations - if there are issues then please let me know. Tibs works with Python 3.10 and later.

How the manual is organised#

The chapters follow the substrate and its two lenses.

The bits as a container

The sequence of bits — construction, indexing, searching, splitting, editing and reordering.

Reading them as typed fields

Typed fields — reading and writing typed values out of the bits.
Views — byte order, bit labels and labelled fields.
Formatting — rendering values with Python’s format mini-language.

Reading them as a set of bits

A set of bits — bitwise algebra, cardinalities and set predicates.

Cross-cutting

Serialization — round-tripping arbitrary-length values through bytes.
Tibs vs Mutibs — choosing between the immutable and mutable types.

The manual covers the major features but is not exhaustive — see the API docs for every method and parameter, and the Appendices for background on byte and bit order and the encoded byte format.
